◆ Features

ZF7L optical glass is a type of heavy flint glass characterized by its high refractive index and high dispersion. It is specifically designed for correcting chromatic aberration in optical systems.

High-precision surface figure control and strict material specifications.

High optical uniformity and low stress birefringence ensure the consistency of optical performance.

◆ Common Specifications

◆ Applications

Imaging optical systems

Substrates for beam-splitting elements of spectrometers

Industrial inspection windows

Optical experimental components for education and scientific research

Dimensional requirements: The outer diameter and thickness shall be determined based on the spatial layout of the optical system and the beam size.

Mounting configuration: All circular lenses from Mloptic can be mounted on standard lens sleeves, fixed lens mounts, and various coaxial mounting plates.

Cleaning taboos: Do not use abrasive cleaning agents or hard tools (such as metal brushes) for cleaning, as they may damage the surface optical quality. It is recommended to use optical-specific cleaning agents such as anhydrous ethanol or isopropyl alcohol, and gently wipe with a soft, lint-free cloth. After cleaning, the surface must be thoroughly dried to prevent contamination from residual liquids.

Transportation and storage: Optical surfaces must be strictly protected during transportation. When packaging, direct contact between protective films and optical surfaces is prohibited to prevent contamination by foreign substances or scratches.
